AP RACING

1 pair of ap racing - cp7040 6pot calipers for 4WD 4X4 SUV (suits from 17" wheels)

Code: CP7040-ap racing
Add Your Review
1 pair of ap racing - cp7040 6pot calipers for 4WD 4X4 SUV (suits from 17" wheels)
$3,659.00 $2,999.00
In Stock
Category: AP, Brakes, HOT SALE PRODUCTS



1 pair of ap racing - cp7040 6pot calipers





CP7040 Family - Suits Ø362x32mm Disc - 16.8mm Thick Pad

 Applications:
- Performance Road Front.
- Factory Big Brake Kits.

Features:
- Radial Mount, 152mm centres.
- Suits Ø362 x 32mm thick discs.
- Cast two piece Aluminium alloy body.
- Aluminium alloy pistons.
- Boot type dirt seals fitted.
- Advanced Red or Black anti-corrosion paint finish.
- Steel wear plates.
- Pad anti-rattle clip fitted.

Black Gloss Caliper Part Numbers:
- RHT = CP7040-2S0BG19 / - LHT = CP7040-3S0BG19.
- RHL = CP7040-4S0BG19 / - LHL = CP7040-5S0BG19.

Black Semi-Gloss Caliper Part Numbers:
- RHT = CP7040-2S0BK2 / - LHT = CP7040-3S0BK2.
- RHL = CP7040-4S0BK2 / - LHL = CP7040-5S0BK2.

Red Caliper Part Numbers:
For Red calipers add 'R38' to end of Part Number e.g.
CP7040-2S0R38

  • Brake Pad Information
    (To view an image of the pad
    click on Pad Part No)

    CP7040D61

    - Pad Area = 72.5cm²
    - Pad Depth = 61.0mm
    - Thickness = 16.8mm
    CALIPER TECHNICAL SPECIFICATIONS
    Piston Sizes - mm - Ø27.0 x 2 / - Ø31.8 x 2 / - Ø38.1 x 2
    Piston Area - cm³ 50.1
    Disc Diameter - mm Ø362.0
    Disc Thickness - mm 32.0
    Weight (no pads) - Kg 3.7
    Hydraulic Threads M10x1.0
    Mounting Type Radial
    Mounting Centres - mm 152.0
    Mounting Offset - mm 53.2
    Mounting Hole Ø - mm 12.1
    ‘PL’ Dimension - mm 68.8
    Bleed Screw Tightening Torque 17Nm
    CALIPER SPARES
    Pistons - Ø27.0 = CP7040-118
    - Ø31.8 = CP6609-106
    - Ø38.1 = CP6200-104
    Seal Repair Kit CP4525-CEJ
    Pad Retainer Type / Part No Pin / CP6600.-109 x 2
    Wear Plates CP7040-110 x 4
    Bleed Screw CP3880.1
    Anti-Rattle Clip CP7040-115
